Technical index:

Power supply: +24V DC,

Output: 4～20mA, maximum load Resistance 750Ω.

1. Vibration measurement

Type of measurement: vibration velocity; Measurement range: 0-20 mm/s, composition error of vibration measurement: ±1㎜/s can be customized at customer's request;

Measurement frequency response: 6～1000Hz, can be customized at customer's request;

Maximum measure acceleration: ±5g;

Non-linearity of amplitude: ≤±2%.

2. Temperature measurement:

Sensor: Pt100, length of connecting rod can be changed according to requirement;

Measurement range: 0~+100℃, composition error of temperature measurement: ±1℃, can be customized at customer's request;

Exact measurement: ±0.5%×F.S

3. Oil-position measure:

Sensor: LVDT(linear differential transforming type displacement sensor)

Measurement range: -10～40mm, composition error of oil-position measure: ±5㎜

Working temperature: -40℃~+150℃;

Storage temperature: -40℃~+100℃;

Humidity: 95％noncoagulating;

Weight: about 900g.
