I. Model: non-isolated type, isolated type
II. Functions:
1. It is compatible with all resistance signal type sensors;
2. Module has self-correcting function;
3. Strong anti-interference function;
4. Four-wire remote input function.
5. 4~20mA output function;
6. Power voltage: AC 24V, working voltage 8~32V (isolated type 12~32V)
III. Precision:
“Zero temperature excursion” high precision platinum resistor intelligent integrated temperature transmitter is a high-end product which can conduct nonlinear calibration correction on error of platinum resistor probe, temperature drift error of transmitter electronic circuit with full measuring range.
IV. Applicable environmental temperature (maximum range): -50℃~400℃
V. Uses:
1. In severe environment temperature, and has high requirement on measurement accuracy.
2. Remote signal collection.
3. Precision temperature measurement.
4. Precision thermal field verification.
|
