TDP-2-06 type displacement transmitter can be configured with LVDT type displacement sensor.

Technical parameters

●Measurement range: 0~1000mm;
●Power supply: DC24V or AC220V, 50Hz,power consumption<6W.
●Input signal: accept one LVDT displacement sensor singal
●Precision: ±1%
●Output
Current output: 4～20 mA Output load: ≤500 Ω
Voltage output: 1～10 V Output load: ＞10KΩ
●Working temperature: -25℃～+60℃
●Storage temperature: -40℃～+85℃
●Relative humidity: 90%
