The product has features such as wide measuring range, high precision, convenient installation, durable in use, continuous use, etc.

• Technical parameters
  1. Measuring range: 0-50mm
  2. Linear accuracy: 0.5 grade; 1 grade
  3. Output signal (load impedance)0～20mA (1KΩ); 1～10V (750Ω);
  4. Secondary instrument: 3-bit semi-LED digital meter
  5. Power supply: AC220V±10％
  6. Power consumption: 5W
  7. Environment temperature: Sensor: -20°C～+150°C Secondary table: normal temperature
  8. Relative humidity: ＞85％
  9. Manner of working: continuous
  10. Excitation frequency: 0～10KHz
