The product can be widely used in aviation, aerospace, electricity, petrochemical industry, machinery, military industry, textile, automobile, coal, seismic surveillance, college, and other fields.
Technical parameters:
1. Linear measuring range: ± 10 ～± 800mm
2. Precision: 0.25%
3. Sensitivity: 2.8 ～ 230mV/V/mm
4. Primary excitation voltage: 1 ～ 20VAC
5. Excitation frequency: sine wave and square wave 400HZ ～ 10KHZ
6. Environment temperature: -50 ℃～ +280 ℃
7. Sensitivity drift: 0.025%/ ℃
8. Load impedance: 20K Ω
Structure chart:
|
Model
|
Stroke
|
φ D
|
I size
|
|
One way
|
Two way
|
|
(mm)
|
± (mm)
|
± ( mil )
|
|
400TD
|
0-20
|
10
|
0.40
|
Φ 6
|
120
|
|
500TD
|
0-25
|
12.5
|
0.50
|
Φ 6
|
140
|
|
700TD
|
0-35
|
17.5
|
0.70
|
Φ 6
|
160
|
|
1000TD
|
0-50
|
25
|
1.00
|
Φ 6
|
188
|
|
2000TD
|
0-100
|
50
|
2.00
|
Φ 6
|
272
|
|
3000TD
|
0-150
|
75
|
3.00
|
Φ 6
|
350
|
|
4000TD
|
0-200
|
100
|
4.00
|
Φ 6
|
400
|
|
5000TD
|
0-250
|
125
|
5.00
|
Φ 6
|
505
|
|
6000TD
|
0-300
|
150
|
6.00
|
Φ 6
|
600
|
|
7000TD
|
0-350
|
175
|
7.00
|
Φ 6
|
700
|
|
8000TD
|
0-400
|
200
|
8.00
|
Φ 6
|
750
|
|
10000TD
|
0-500
|
250
|
10.00
|
Φ 6
|
860
|
|
12000TD
|
0-600
|
300
|
12.00
|
Φ 6
|
980
|
|
